Frame
All New Series 4 Alloy Frame, 140mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor
Rear Shock
Fox Float X, Performance Elite Series, EVOL Air Spring, Climb Switch, Rebound Adjustment, Custom Tune, 210x50mm, M8x30mm Top, M8x25mm Bottom
Fork
Fox 36 Performance Elite, 140mm travel, 29", 110x15mm Boost Kabolt Thru-Axle, 44mm Offset, Integrated Fender
Headset
FSA No 57, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Stem
Marin CNC, 35mm Length, 35mm Bar Bore
Handlebar
Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back
Grips
Marin Grizzly Lock On
Saddle
Marin E-MTB Saddle
Seatpost
X-Fusion Manic, 1x Composite Remote, Size S 125mm Travel, Size M and L 150mm Travel, Size XL 170mm Travel, 30.9mm
Brakes - Rear
TRP DH-R Evo, 4-Piston Hydraulic Disc, Metallic Pads, 203mm Rotor w/ Speed Sensor
Brakes - Front
TRP DH-R Evo, 4-Piston Hydraulic Disc, Metallic Pads, 203mm Rotor
Shifter
Shimano Deore XT SL-M8130-R, LinkGlide
Derailleur
Shimano, Deore XT RD-M8130, 11-Speed, SGS, LinkGlide
Cassette
Shimano XT LinkGlide LG-600, 11-Speed, 11-50T
Chain
KMC E-11S
Crank
Shimano XT M8150, 160mm Length, 38t Chainring
Rims
Marin Aluminum Double Wall, 29" Diameter, 29mm Inner Rim Width, Sleeved Joint, Disc Specific, Tubeless Compatible
Front Hub
Shimano MT-410B, 110x15mm, Centerlock Disc, 32H
Rear Hub
Shimano HB-MT510B, 148x12mm, Centerlock Disc, Micro Spline Freehub Body
Tyres
Vee Tire Co. Attack HPL, 29x2.5", Top 40 Tubeless Compatible, Override E-Specific Casing
Motor
Shimano Steps EP801 Drive Unit, 250W, 85Nm
Battery
Shimano BT-EN806, Internal 630Wh
Display
Shimano SC-E600
Switch
Shimano SW-EN600L Left Hand Switch for Assist Mode Change
Charger
Shimano Battery Charger EC-E6002
EXTRAS - Shimano Battery Charger EC-E6002, Shimano CS-EN800 Chainguide.
Specifications, pricing, and availability are subject to change without notice.
